Chapter 6 Specifications RIGOL

User’s Guide for DM3068

6-17

[2]

Use the default delay setup rate (the default trigger delay).

[3]

The maximum rate available when trigger delay is set to 0.

[4]

20V range, fast filter, 1kHz input.

[5] Measure 20nF capacitance on 200nF range. The measurement period changes with the capacitance under test. The maximum measurement period on

100mF is 4s (typical value).
