RIGOL

Programming Guide for DS1000B Series

2-70

Example:

:TRIGger:ALTernation:EDGE:SLOPe□POSitive, SOURceB

Set the edge type as rising edge.

:TRIGger:ALTernation:EDGE:SLOPe?□SOURceB Return POSITIVE.

(8) :TRIGger:ALTernation:PULSe:MODE

Command Format:

:TRIGger:ALTernation:PULSE:MODE□<value>[,<source>]

Function:

The command sets the trigger condition of pulse trigger. The <value> may

be +GREaterthan, +LESSthan, + EQUal, -GREaterthan, -LESSthan or

–EQUal. The <source> may be SOURceA or SOURceB, and the source A

and B are varying with the current alternation channel.

Query Format:

:TRIGger:ALTernation:PULSe:MODE?□[<source>]

Return Format:

The query returns +GREATER THAN or +LESS THAN, +EQUAL, -GREATER

THAN, -LESS THAN, –EQUAL.

Example:

:TRIGger:ALTernation:PULSe:MODE□+GREATERTHAN, SOURceB

Set the trigger condition as +GREATER THAN.

:TRIGger:ALTernation:PULSe:MODE?□SOURceB

Return +GREATER THAN．

(9) :TRIGger:ALTernation:PULSe:TIME

Command Format:

:TRIGger:ALTernation:PULSe:TIME□<value>[,<source>]

Function:

The command sets the pulse width, the value range is 20ns~10s. The

<source> may be SOURceA or SOURceB, and the source A and B are

varying with the current alternation channel.
